HANTEK DSO-8072E 2CH 70 MHz Scope


DSO8000E Series

Six in one: Oscilloscope/Recorder/DMM/ Spectrum Analyzer/Frequency Counter/Arbitrary Waveform generator. IP-51 rated for dust, drip and shake proof to withstand harsh environments. Large fuse confirms to European Safety Standard. Battery indicator with easy-changed connect points. Selectable 18650 battery box for matching 18650 battery by yourself. Anti-theft lock hole, tripod fixed hole, hang rope, FLASH light that can be used in darkness. Replaceable BNC safety joints, and additional one set of joints. 1GSa/s sample rate, 2M Memory depth, 6000 counts DMM. Large 5.6 inch TFT Color LCD Display; High Resolution(640*480)

Manual en: User Manual DSO8000E [2'085 KB]

Technical Data : Tech Data DSO8000E Series

  • Six in one: Oscilloscope/Recorder/DMM/ Spectrum Analyzer/Frequency Counter/Arbitrary Waveform generator.
  • IP-51 rated for dust, drip and shake proof to withstand harsh environments.
  • Large fuse confirms to European Safety Standard.
  • Battery indicator with easy-changed connect points. Selectable 18650 battery box for matching 18650 battery by yourself.
  • Anti-theft lock hole, tripod fixed hole, hang rope, FLASH light that can be used in darkness.
  • Replaceable BNC safety joints, and additional one set of joints.
  • High bandwidth 70MHz-200MHz Oscilloscope, 1GSa/s sample rate, 2M Memory depth.
  • 25Mz Arb. Waveform Generator, 200 Mesa/s DDS, 12 bit vertical resolution, easy for simulating transducer
  • 6000 Counts DMM, AC/DC voltage, AC/DC current, resistance, break, capacitance, and diode function.
  • FFT spectral analysis; Waveform Math: add, subtract, multiply and divide; X-Y mode; more than 20 automatic measurements; PASS/FAIL Check function, apply to engineering application.
  • Abundant trigger function, double timebase sampling, easy to observe two waveforms in different frequency.
  • Record and replay of more than 1000 waveforms.
  • Large 5.6 inch TFT Color LCD Display; High Resolution(640*480)
  • USB Host/Device 2.0 full-speed interface; support removable disk; WIFI/LAN Option, easy to control by PC or long-distance.
  • Waveform data can be output in WORD,EXCEL, BMP, JPG as time and voltage.

Lieferumfang

  • Messgerät
  • Li-Ionen Akku (eingebaut, austauschbar)
  • 2 x Messprobe für Oszilloskop
  • 1 x Messproben für Multimeter
  • CD mit Handbuch und Software (E)
  • Netzteil
  • gepolsterte Tragetasche
  • 2 Jahre Garantie


749.00 CHF

Artikel-Nr: HAN-8072E

unser Unternehmen ist nicht mehrwertsteuerpflichtig

ab Lager lieferbar

Anzahl:   St



‹bersicht Hantek Handoszilloskope


Alle Handoszilloskope verfügen über einen eingebauten
(austauschbaren) Li-Ionen Akku!

HANTEK DSO-8072E 2CH 70 MHz Scope Six in one: Oscilloscope/Recorder/DMM/ Spectrum Analyzer/Frequency Counter/Arbitrary Waveform generator. IP-51 rated for dust, drip and shake proof to withstand harsh environments. Large fuse confirms to European Safety Standard. Battery indicator with easy-changed connect points. Selectable 18650 battery box for matching 18650 battery by yourself. Anti-theft lock hole, tripod fixed hole, hang rope, FLASH light that can be used in darkness. Replaceable BNC safety joints, and additional one set of joints. 1GSa/s sample rate, 2M Memory depth, 6000 counts DMM. Large 5.6 inch TFT Color LCD Display; High Resolution(640*480) 749.00 CHF

AKTION 10% - HANTEK DSO-1072E 2CH 70 MHz Scope 5-in-1 Scope - Recorder - DMM - FFT Spectr. analyzer - Freq-Counter - 5.7" Farbdisplay mit 640x480 Bildpunkten.Speichertiefe 1M Single Channel - 512k Dual Channel. DMM with analog bargraph. 645.00 CHF
